Powersafe SLD0016 Line Drain 800A 240mm2 Crimp 22-32mm Black Neutral IP67

Description

Full-size neutral for 800A power sets.

The Powersafe SLD0016 is a black Neutral drain from the 800A end of the Powerlock-compatible Powersafe family, crimped onto 240mm² copper cable. It lets the neutral conductor match the phase connectors in a high-current single pole set.

Key Features

• Black, keyed to the Neutral (N) position
• Powerlock-compatible line drain in the 800A series
• Male insulator around a female contact
• 240mm² copper cable, hydraulic crimp termination
• M40B gland with a 22–32mm clamping range
• 1000V AC rated operating voltage
• Short circuit rating to 35.5kA with 75kA surge current
• IP67 sealing, plus IP2X finger-proofing on the unmated contact
• Flame retardant shell to UL94-V0
• Contact silver plated, with a mating life above 500 cycles

Shop now and have it dispatched fast, Australia-wide.

A Neutral Sized for the Job

Inside the 800A contact
Powersafe reaches its 800A continuous rating through 29 transfer bridges in the contact, each one rated at 30A, which adds up to 870A. Phase 3 supplies its 800A connectors for 240mm² and 300mm² cable. The current a finished lead can carry continuously is still governed by the cable selected and the conditions it runs in.

Neutral by key, not just by colour
Black is used for more than one line across different Powersafe colour schemes, so the key position is what matters. This drain is keyed Neutral and joins only to a Powersafe Neutral source connector, cable or panel mounted. A secondary lock then holds the pair until a release key is inserted. Being the drain, it is normally the receiving, non-live end once unplugged.

Making the crimp

• Bare 43mm of conductor at the cable end
• Load the ME 48 hexagonal die into either hydraulic tool, the HT 131-C or the B 131-C
• Crimp three times, evenly spaced, along the contact
• Screw on the gland and tighten body and dome nut to 11 Nm

Only for copper conductors. Work on this connector belongs with a licensed electrician following Australian wiring rules, and the crimp should be tensile tested.

Q: What cable size does the Powersafe SLD0016 take?
A: It has a crimp contact for 240mm² copper cable, and its M40B gland clamps cable with an overall diameter between 22mm and 32mm.

Q: Is the black SLD0016 a neutral or a phase connector?
A: It is a Neutral connector. The mechanical key sets this, and it will only mate with a Powersafe Neutral source.

Q: Can the SLD0016 be used with existing Powerlock leads?
A: Phase 3 states that Powersafe mates with Litton VEAM, ITT Cannon, 400A and 660A Powerlock and similar Powerlock-style connectors, as long as both halves share the same key position.
