Tesla TRCD2P10E 10 Amp RCD/MCB Safety Switch RCBO 6kA Electronic Double Module 240V IEC61009-1

Description

Earth leakage and overcurrent protection in one double module.

The Tesla TRCD2P10E is a two pole 10 amp RCBO safety switch with a 6kA breaking capacity. It combines residual current (earth leakage) protection and overcurrent (circuit breaker) protection in a single two module device built to IEC61009-1, switching both the active and neutral conductors.

Key Features

• Two pole (2P) RCBO safety switch, combined RCD and MCB
• Rated current: 10A
• Breaking capacity: 6kA (6000A)
• Electronic type
• Rated voltage: 240V
• Rated frequency: 50/60Hz
• Two module width
• Separate RCD trip flag for fast fault finding
• Top and bottom line load compatible
• No need to cut the busbar for fit off
• Mechanical life: 10,000 cycles
• Electrical life: 4,000 cycles
• IP20 rated
• Standard: IEC61009-1

Add to cart now for fast dispatch right across Australia.

Why it Matters

Two Protections in One Device
An RCBO combines the earth leakage protection of an RCD with the overload and short circuit protection of a circuit breaker in a single unit. On a two module footprint the TRCD2P10E delivers both functions on a single 10 amp circuit, switching the active and neutral together. That gives a final subcircuit its own dedicated safety switch without needing a separate RCD and MCB side by side on the rail. Combining the two functions in a single two module unit also frees up space in the enclosure, which matters on a board where every module counts.

Electronic Operation for Reliable Detection
This is the electronic variant of the Tesla two pole safety switch range. It is built to IEC61009-1 with a 6kA breaking capacity, giving headroom on boards with a higher prospective fault current than a basic domestic supply. Rated at 240V and 50/60Hz, it is made for standard Australian single phase circuits, and its 4,000 cycle electrical life and 10,000 cycle mechanical life reflect a device built for regular switching duty. The 6000A breaking capacity is the rated figure on the JVL5 series, and the IP20 rating suits installation inside an enclosed switchboard rather than exposed mounting.

Built for Faster Switchboard Work
Practical features make fit off and fault finding quicker on a working board. A separate RCD trip flag shows at a glance whether a trip was caused by earth leakage rather than overload, so fault finding is faster. The device is top and bottom line load compatible, and there is no need to cut the busbar to fit it, which keeps installation clean and reduces labour on the board. Because it is top and bottom line load compatible, the incoming supply can be landed on either end, giving flexibility in how the device is wired into an existing board layout.

Part of the Tesla JVL5 Safety Switch Range
The TRCD2P10E sits in the Tesla JVL5 series of combination RCD and MCB safety switches, which spans a range of current ratings. As the electronic 10 amp two pole device it covers a single final subcircuit, and it shares the same two module format, IEC61009-1 build and V08030 approval as the wider electronic range, keeping a switchboard consistent across circuits.

Is the TRCD2P10E an RCBO?
Yes. It is a combined RCD and MCB safety switch built to IEC61009-1, providing both earth leakage and overcurrent protection in one two module device.

How many poles does the TRCD2P10E switch?
It is a two pole device, switching both the active and neutral conductors on a single phase circuit.

What is the breaking capacity of the TRCD2P10E?
It has a 6kA (6000A) breaking capacity, suited to circuits with a higher prospective fault current than a basic domestic supply.
