Tesla TRCD2P25E 25 Amp 2 Pole RCD/MCB Safety Switch 6kA Electronic Double Module 30mA Curve C

Description

Double-module protection, three jobs done.

The Tesla TRCD2P25E is an electronic RCBO that rolls overload, short-circuit and earth-leakage protection into a single 2 module unit. Rated at 25A with a 6kA breaking capacity and 30mA residual sensitivity, it clips straight onto 35mm DIN rail and frees up valuable board space.

Key Features

• Rated current: 25A
• Breaking capacity: 6kA
• Residual current sensitivity: 30mA
• Tripping curve: C
• 2 Pole, 2 module (double module) width
• Electronic operating type
• Rated voltage: 240V, 50/60Hz
• Standard: IEC61009-1
• Separate RCD trip flag for fast fault finding
• Top and bottom line-load compatible
• 35mm DIN rail mounting

Buy online now for fast dispatch Australia-wide.

Why it Matters

Combined protection in less space
An RCBO does the work of an MCB and an RCD in one device. The TRCD2P25E guards against overload and short circuit while its 30mA residual element disconnects the circuit on earth leakage. A single 2 module footprint therefore delivers full circuit protection where separate MCB and RCD devices would take more room on the DIN rail. For installers, that means fewer components to wire, fewer terminations to check, and a neater final board. The 6kA breaking capacity gives headroom for the prospective fault levels seen on many Australian distribution boards.

Faster fault finding
A dedicated RCD trip flag shows at a glance whether a trip was caused by earth leakage or by overcurrent. On a busy switchboard that single indication removes guesswork, saves diagnostic time, and helps get the affected circuit back in service sooner. Because each RCBO protects its own circuit individually, an earth-leakage fault on one final subcircuit trips only that device rather than taking out a shared upstream RCD and everything downstream of it.

Straightforward switchboard fit-off
Top and bottom line-load compatibility means the unit can be fed from either end, simplifying busbar arrangements and wiring runs. Mounting is on standard 35mm DIN rail, and the electronic design keeps the device to a compact 2 module width for tidy, repeatable installs. Because the busbar does not need to be cut to suit, fit-off stays quick and repeatable across a full board of devices. Mechanical endurance is rated at 10,000 cycles and electrical endurance at 4,000 cycles, and the unit carries an IP20 rating for enclosed switchboard use.

Curve C for general circuits
The C tripping curve is the common choice for mixed lighting and power final subcircuits, tolerating the moderate inrush of everyday loads without nuisance tripping while still clearing genuine overloads and short circuits. Paired with the 6kA breaking capacity, the TRCD2P25E is suited to the prospective fault levels found on typical Australian distribution boards.

Tesla TRCD2P25E 25 Amp Electronic RCBO 6kA 30mA
Compliant to IEC61009-1 and rated for 240V at 50/60Hz, this electronic RCBO carries a C tripping curve and a 30mA rated residual operating current. It is one member of Tesla's 2 pole electronic RCBO range, which shares a common 2 module body across its rated-current options, so boards can be populated with a consistent module height and appearance.

Is the Tesla TRCD2P25E a combined RCD and circuit breaker?
Yes. It is an RCBO, meaning it provides residual current (earth leakage) protection and miniature circuit breaker overload and short-circuit protection in one 2 module device.

What earth leakage sensitivity does the TRCD2P25E trip at?
It has a rated residual operating current of 30mA, the level used for personal protection on Australian final subcircuits.

Does the TRCD2P25E mount on standard DIN rail?
Yes. It mounts on 35mm DIN rail and occupies a 2 module (double module) width on the switchboard.
