Tesla TMCBO232MA 32 Amp 2 Pole RCBO Safety Switch 6kA 30mA Type A

Description

Earth leakage and overload protection in one device.

The Tesla TMCBO232MA combines RCD and MCB functions in a single 36 mm module. A 32 amp final subcircuit gets earth leakage, overload and short-circuit protection without consuming two separate switchboard positions.

Key Features

• Rated current 32 A
• Rated residual operating current 30 mA
• Breaking capacity / Ics 6,000 A (6 kA)
• Type A operating characteristic
• 1P + N, switched neutral, 36 mm
• Rated voltage 230/240 V AC, 50/60 Hz
• Protects against earth fault and leakage current, short-circuit and overload
• Accepts rigid conductors up to 25 mm²
• Available for both comb and busbar
• Mechanical life 10,000 cycles, electrical life 4,000 cycles
• IP20 rated
• Manufactured to IEC/EN AS/NZS 61009-1

Add to cart now for fast dispatch Australia-wide.

One Device, Three Protection Functions

An RCBO does the work of a residual current device and a miniature circuit breaker together. This unit provides protection against earth fault and leakage current, short-circuit and overload, plus complementary protection against direct contact by the human body. That combination protects personal safety, helps prevent electrical fires, and stops connected equipment being damaged by fault conditions.

Because the device switches the neutral as well as the active, the protected circuit is fully isolated when the unit trips or is switched off. At 36 mm wide it occupies the same space as two standard modules, so per-circuit RCD protection can be built into a distribution board one subcircuit at a time.

Type A Sensing and 6 kA Capacity

The unit carries a Type A operating characteristic. Under AS/NZS 61009-1, Type A devices are specified to respond to both sinusoidal AC residual currents and pulsating DC residual currents. The 30 mA rated residual operating current is the sensitivity level used for personal protection.

A breaking capacity and Ics of 6,000 A suits distribution boards on supplies where prospective fault current reaches 6 kA. Ics is the service breaking capacity, meaning the device is rated to clear that fault level and remain serviceable afterwards. The 32 A rating covers heavier final subcircuits such as fixed appliance and dedicated equipment runs.

The Tesla datasheet lists this two pole RCBO series across rated currents of 6, 10, 16, 20, 25, 32 and 40 A, with 10 mA and 30 mA residual sensitivities. A board can therefore be populated from a single consistent series rather than mixing devices from different ranges.

Built for Switchboard Assembly

Terminals accept rigid conductors up to 25 mm², and the device is available for use with both comb and busbar, which keeps multi-pole board builds tidy and repeatable. An IP20 rating suits mounting inside an enclosed switchboard or distribution board rather than in an exposed position.

A mechanical life of 10,000 cycles and an electrical life of 4,000 cycles give switchboard builders and electricians a device rated for long service in power distribution systems. Tesla lists this RCBO family for use in commercial and industrial installations.

Is the Tesla TMCBO232MA an RCD or a circuit breaker?
It is both. As an RCBO it provides earth fault and leakage protection like an RCD, plus overload and short-circuit protection like a circuit breaker, in one 36 mm device.

What residual current does this Tesla RCBO trip at?
It has a rated residual operating current of 30 mA, which is the standard sensitivity used for personal protection on final subcircuits.

Can the Tesla TMCBO232MA be connected to a busbar?
Yes. Tesla lists this RCBO as available for both comb and busbar, and the terminals accept rigid conductors up to 25 mm².
