Tesla TESTRCD2P32EA RCBO 2 Pole 6kA 32 Amp

Double-module protection for higher-current circuits.

The Tesla TRCD2P32E electronic RCBO combines overload, short-circuit and earth-leakage protection in one compact device. Rated at 32A with a 6kA breaking capacity and 30mA residual sensitivity, it mounts directly onto standard 35mm DIN rail and occupies just two modules.

Key Features

• Rated current: 32A
• Breaking capacity: 6kA
• Residual current sensitivity: 30mA
• Tripping curve: C
• 2 pole, 2 module width
• Electronic operating type
• Rated voltage: 240V, 50/60Hz
• Standard: IEC 61009-1
• Separate RCD trip flag for faster fault finding
• Top and bottom line-load compatible
• 35mm DIN rail mounting
• IP20 rating
• Mechanical endurance: 10,000 cycles
• Electrical endurance: 4,000 cycles

Buy online now for fast dispatch Australia-wide.

Combined circuit protection

An RCBO combines the functions of a miniature circuit breaker and residual current device. The TRCD2P32E protects against overloads and short circuits while its 30mA residual element detects earth leakage.

Providing both forms of protection in a single two-module device reduces the number of separate components required. This helps installers achieve a neater switchboard layout with fewer devices and terminations to manage.

Clear trip indication

A separate RCD trip flag helps identify whether a trip was caused by earth leakage rather than an overload or short circuit. This allows electricians to diagnose faults more quickly and reduces guesswork during switchboard maintenance.

Because the RCBO protects an individual final subcircuit, an earth-leakage fault can be isolated to that circuit instead of disconnecting multiple circuits connected to a shared upstream RCD.

Flexible switchboard installation

Top and bottom line-load compatibility allows the TRCD2P32E to be supplied from either end, providing greater flexibility when arranging busbars and cable runs.

The unit clips onto standard 35mm DIN rail and occupies a consistent two-module footprint. Its electronic design, compact dimensions and flexible connection arrangement support tidy, repeatable switchboard installations.

32A Curve C protection

The 32A rating makes this RCBO suitable for appropriately designed higher-current final subcircuits and equipment loads. Its Curve C tripping characteristic accommodates moderate starting currents while still providing overload and short-circuit protection.

Circuit selection and installation must be completed by a licensed electrician, taking into account the cable size, connected load and prospective fault current.

Tesla TRCD2P32E 32 Amp Electronic RCBO 6kA 30mA

The Tesla TRCD2P32E is a 2 pole electronic RCBO rated at 32A and 240V AC, 50/60Hz. It features a C tripping curve, 30mA residual operating current and 6kA short-circuit breaking capacity.

It forms part of Tesla’s two-module electronic RCBO range, allowing different circuit ratings to be installed with a consistent height, width and switchboard appearance.

Is the Tesla TRCD2P32E an RCD and circuit breaker combined?

Yes. As an RCBO, it provides earth-leakage protection together with overload and short-circuit protection in one two-module device.

What is the earth-leakage sensitivity of the TRCD2P32E?

The TRCD2P32E has a rated residual operating current of 30mA.

How much switchboard space does the TRCD2P32E require?

It occupies two modules and mounts onto standard 35mm DIN rail.

What circuits can a 32A RCBO protect?

A 32A RCBO may be used on appropriately designed final subcircuits where the cable size, connected load and installation conditions support a 32A protective device. Suitability must be confirmed by a licensed electrician.
