Tesla TMCB2P10 MCB 2 Pole 10 Amp 6kA C-Curve Miniature Circuit Breaker 415V HPC2 Series Overload and Short Circuit Protection

Description

Dependable two pole protection for critical circuits.

The Tesla TMCB2P10 is a 2 pole, 10 amp miniature circuit breaker from the HPC2 Series, delivering a 6kA breaking capacity with C-curve tripping characteristics. It guards against overload and short circuit in the electrical distribution system, suiting commercial, domestic and industrial applications.

Key Features

• Rated current: 10A
• 2 pole, 2 module format
• Breaking capacity: 6kA (6000A)
• C-curve tripping characteristics
• Rated voltage: 415V
• Rated frequency: 50/60Hz
• Bi-metal tripping mechanism for overload protection
• Pillar terminal with clamp, rigid conductor up to 25mm²
• Mechanical life: 10,000 cycles; electrical life: 4,000 cycles
• Standard: IEC/EN60898; approval number V08030; IP20

Order today for fast dispatch Australia-wide.

Protection You Can Count On

Every circuit needs a device that reacts the moment something goes wrong. The TMCB2P10 combines two forms of protection in one compact unit. Its bi-metal tripping mechanism responds to sustained overload, disconnecting the circuit before conductors overheat and insulation is damaged. Against short circuits, the breaker safely interrupts fault currents up to its 6000A rated breaking capacity, built and tested to the IEC/EN60898 standard for miniature circuit breakers. Because both poles switch together, a fault on the circuit sees the supply broken across the pair rather than a single conductor, which is exactly what a two pole device is specified to do. That 6000A figure matters because fault current in a distribution board can far exceed the circuit's normal 10 amp load, and the breaker has to clear it cleanly without failing.

C-Curve Performance for Everyday Loads

Tesla builds this breaker with C-curve tripping characteristics, the profile the manufacturer nominates as suiting most applications. That makes the TMCB2P10 a straightforward choice across commercial, domestic and industrial installations where general power and lighting circuits need reliable overcurrent protection at a 10 amp rating. It sits within the HPC2 Series family that spans 1, 2 and 3 pole configurations with rated currents from 10A through to 63A, so switchboards can be populated consistently from a single breaker range. Where a motor-start profile is required instead, Tesla's D-curve versions carry a D suffix on the product code, so the plain TMCB2P10 code always identifies the C-curve unit.

Practical Design at the Switchboard

The two module footprint keeps panel space in check while the pillar terminals with clamp accept rigid conductors up to 25mm², giving installers secure, tidy terminations without stray strands or hot joints working loose. Rated at 415V and 50/60Hz, the breaker is matched to Australian distribution voltages, and endurance is rated at 10,000 mechanical cycles and 4,000 electrical cycles for a long service life of routine switching and fault clearing. The unit carries an IP20 rating along with Australian approval number V08030. Each breaker is supplied individually, with a box quantity of 6 and a carton of 60 for trade and wholesale purchasing.

What is the breaking capacity of the Tesla TMCB2P10?
The Tesla TMCB2P10 has a breaking capacity of 6kA, meaning it can safely interrupt fault currents up to 6000 amps in accordance with the IEC/EN60898 standard for miniature circuit breakers.

Is the Tesla TMCB2P10 a C-curve or D-curve circuit breaker?
The TMCB2P10 is a C-curve breaker, the characteristic Tesla nominates for most applications. The D-curve motor-start versions are separate products identified by a D suffix on the product code.

What cable size do the TMCB2P10 terminals accept?
The TMCB2P10 uses pillar terminals with a clamp that accept rigid conductors up to 25mm² for secure connection in the switchboard.
