Red Smoke RWB2 Wireless Mounting Base for R240 R240RC Smoke Alarms

Description

Add wireless interconnect to your 240V alarms.

The Red Smoke RWB2 is a wireless mounting base for the R240 and R240RC 240V smoke alarms. Fit the alarm to this base and it links by radio to other Red alarms – including the R10RF wireless alarm – so a trigger on one sounds them all, with no interconnect cable to run between them.

Key Features

• Wireless mounting base for the R240 and R240RC 240V smoke alarms
• Wirelessly interconnects with Red 240V alarms and the R10RF wireless alarm
• Connects to the Red Smoke wireless controller (RAC / RACP)
• Non-replaceable 3V lithium battery, 10-year life
• 433.92 MHz; up to 40 wired or 20 wireless interconnected alarms
• 30m line-of-sight range indoors, 100m free field (150m wired)
• Screw terminals (active, neutral, earth loop, interconnect), 2 x 1.5mm²
• Conduit and ceiling knockouts for surface or ceiling mounting
• Tested to AS 4268 and AS/NZS CISPR 32:2015

Add one to your cart for fast dispatch nationwide.

Wireless Interconnect, No Extra Cabling

Running interconnect cable between existing 240V alarms is disruptive. The RWB2 avoids it: mount an R240 or R240RC on the base and the alarms link by radio on 433.92 MHz instead, with 30m line-of-sight indoors and 100m in free field. It carries its own non-replaceable 3V lithium battery so the wireless link keeps working through a mains outage.

Installer-Friendly

The base wires through standard screw terminals for active, neutral, earth loop and interconnect, each taking two 1.5mm² conductors. Two side knockouts suit conduit on a surface mount, and an internal knockout suits a ceiling mount. With the RWB2 fitted, the Red Smoke wireless controller (RAC or RACP) can also test, locate and silence the alarms from a wall point.

Q: What is the Red Smoke RWB2 for?
A: It is a wireless mounting base that adds RF interconnect to the R240 and R240RC 240V smoke alarms, so they can link wirelessly to other Red alarms instead of being hard-wired together.

Q: Does the RWB2 have its own battery?
A: Yes. It contains a non-replaceable 3V lithium battery with a 10-year life, which keeps the wireless link active during a mains power outage.

Q: Can the RWB2 work with the Red Smoke controller?
A: Yes. With the RWB2 fitted, the Red Smoke wireless controller (RAC or RACP) can test, locate and silence the connected alarms wirelessly.

Warranty

Red Smoke Alarms – Manufacturer Warranty

Red Smoke Alarms are built to last and backed by a 10-year warranty for both residential and commercial use. Faults are rare, but if something does go wrong, support is just a call or click away.

To submit a warranty claim, you can either:

• Call Red Smoke Alarms on 1300 316 552, or

• Submit a claim online at: redsmokealarms.com.au/warranty

Red Smoke Alarms are supported by a national network of service agents ready to assist in the unlikely event of a fault.

Note: For the fastest resolution, contact Red Smoke Alarms directly. Warranty claims and repairs are handled exclusively by their team—not through Electrotraders.
