Red Smoke RFMDUAL Flush Mount 240V Photoelectric Smoke Alarm Dual Power

Description

Dual-power protection, flush to the ceiling.

The Red Smoke RFMDUAL is a flush-mount photoelectric smoke alarm with dual power: run it on 240V mains with a sealed 10-year lithium battery backup, or as a standalone 10-year lithium battery alarm. Recessed into a 90mm cut-out, it sits level with the ceiling for a discreet, architectural finish.

Key Features

• Flush-mount design, recesses into a 90mm ceiling cut-out
• Dual power: 240V mains with sealed 10-year lithium backup, or battery-only operation
• Type A photoelectric sensor – detects smouldering and open fires
• Hardwired interconnect, or wireless with the optional RFMOD module (up to 40 combined)
• Sealed 10-year lithium battery (CR123A / CR17335) – no battery changes
• 85 dB alarm at 3m (ISO 8201 pattern), approximately 8-second response
• Test and hush button, with LED status indication
• Certified to AS 3786:2014+A1:2015+A2:2018 (CSIRO ActivFire, cert. afp-3837)
• Approved for QLD Government Housing installation

Add one to your cart for fast dispatch nationwide.

Discreet Flush-Mount Finish

Unlike a surface alarm that sits proud of the ceiling, the RFMDUAL recesses into a 90mm cut-out so the alarm finishes level with the ceiling line. The alarm body is around 110mm in diameter and extends roughly 62mm into the ceiling cavity, so check you have the clearance above the plasterboard before cutting. The result is a clean, low-profile look that suits feature ceilings and quality fitouts. The unit ships in a plastic dust cover – keep it covered through construction and remove it at commissioning.

Dual Power, Flexible Install

Wire the RFMDUAL to 240V mains for continuous operation, with the sealed lithium battery providing standby if mains power is lost. Where there is no mains, it runs on the 10-year battery alone (note there is no separate standby source in battery-only mode). The photoelectric sensor responds well to slow, smouldering fires, and a hush function quietens nuisance alarms for around 10 minutes.

Interconnect a Whole Home

Hardwire the alarms together so that when one detects smoke, they all sound. Where running interconnect cable is not practical, the optional RFMOD wireless module links alarms by radio at 433.92 MHz. Up to 40 alarms can be interconnected in total across wired and wireless. Note the interconnect terminal is for hardwiring directly to other smoke and heat alarms; do not combine RF modules and hardwired interconnect on the same unit.

Q: How is the Red Smoke RFMDUAL powered?
A: By 240V mains with a sealed 10-year lithium battery as standby, or on the lithium battery alone where there is no mains. The battery is not replaceable, so the whole alarm is replaced at end of life.

Q: What size cut-out does the RFMDUAL need?
A: A 90mm ceiling cut-out. The alarm body is about 110mm in diameter and recesses roughly 62mm into the cavity, finishing level with the ceiling.

Q: Is the Red Smoke RFMDUAL compliant for Queensland homes?
A: It is a photoelectric, interconnectable alarm certified to AS 3786:2014 and approved for QLD Government Housing installation. Always confirm placement and interconnection meet current requirements.

Warranty

Red Smoke Alarms – Manufacturer Warranty

Red Smoke Alarms are built to last and backed by a 10-year warranty for both residential and commercial use. Faults are rare, but if something does go wrong, support is just a call or click away.

To submit a warranty claim, you can either:

• Call Red Smoke Alarms on 1300 316 552, or

• Submit a claim online at: redsmokealarms.com.au/warranty

Red Smoke Alarms are supported by a national network of service agents ready to assist in the unlikely event of a fault.

Note: For the fastest resolution, contact Red Smoke Alarms directly. Warranty claims and repairs are handled exclusively by their team—not through Electrotraders.
