Clipsal 66CV463-RO 66 Series Switched Socket Outlet 500V 63A 4 Round Pin IP66 Surface Mount - Chemical Resistant Orange

Description

High-visibility three-phase power, built to resist chemicals and weather.

The Clipsal 66CV463-RO is a 500V, 63A four round pin switched socket outlet in a chemical resistant orange housing. Rated IP66 and built for heavy three-phase loads, its bright orange body keeps large equipment safely connected and easy to spot where dust, moisture and corrosive substances are part of the job.

Key Features

• 500V AC, 63A rated
• 4 round pins
• 4 pole configuration
• IP66 weatherproof rating
• Surface mount
• Chemical resistant orange housing
• 3 modules
• 18 month manufacturer warranty

Order online now for fast dispatch Australia-wide.

Built for Australian Industry

The 66 Series steps the 56 Series formula up to higher currents, and the 63A rating makes this outlet a match for the largest three-phase loads on site. Its robust housing stands up to knocks, UV and the day-to-day punishment of workshops, plant rooms and exposed external walls across Australia. Surface mounting keeps installation straightforward on walls, posts and equipment frames.

The four round pin arrangement delivers three-phase power through a single heavy-duty connection, while integrated switching lets operators isolate the load before plugging or unplugging. That keeps switching controlled and reduces arcing on these higher-current circuits.

Chemical Resistant By Design

The chemical resistant orange housing sets this variant apart from a standard socket. It is intended for environments where corrosive splashes, cleaning agents or industrial chemicals would attack ordinary plastics, and the high-visibility orange finish makes the outlet easy to locate in busy or low-light work areas.

An IP66 rating adds complete dust protection plus resistance to powerful water jets from any direction, so the internal contacts stay dry and the connection stays reliable through repeated wash-downs and dusty conditions alike.

Weatherproof Performance

With its sealed IP66 body and generous 63A capacity, the 66CV463-RO is engineered for continuous industrial duty. It measures 320 mm high, 160 mm wide and 215 mm deep, and is backed by an 18 month manufacturer warranty so specifiers and electricians can fit it with confidence.

Because the 66 Series shares the widely stocked Clipsal industrial ecosystem, matching plugs, connectors and accessories remain easy to source for maintenance and future expansion.

Q: What plug suits the Clipsal 66CV463-RO?
A: It accepts a matching 500V 63A four round pin 66 Series plug or connector.

Q: What is the difference between the orange and grey 66CV463 sockets?
A: They are electrically identical; the orange RO variant uses a high-visibility chemical resistant housing while the grey RG variant uses a chemical resistant grey housing.

Q: Is the 66CV463-RO suitable for outdoor and wash-down use?
A: Yes. It carries an IP66 rating, giving full dust protection and resistance to high-pressure water jets.
