Clipsal 56 Series 56C310-GY Switched Socket Outlet 250V 10A 3 Flat Pin IP66 Grey

Description

Weatherproof power where you need it.

The Clipsal 56C310-GY is an IP66 switched socket outlet rated 250V, 10A with a 3 flat pin configuration. Built for surface mounting in tough outdoor and industrial settings, it delivers reliable switched power in a rugged weatherproof housing that stands up to the elements.

Key Features

• Rated 250V, 10A, 50Hz
• 3 flat pin (1 + Neutral + Earth)
• Single phase
• IP66 weatherproof protection
• Surface mounting
• Screw terminals, 1.5-6mm² capacity
• Conduit entry 2 x M20 / 1 x M25
• ABS housing, phosphor bronze pins
• Dimensions 204 x 101 x 83mm
• Grey finish
• Built to AS/NZS 3133 and AS/NZS 3123

Get yours now for fast dispatch Australia-wide.

Why it Matters

Built for harsh conditions
The IP66 rating means the enclosure is fully protected against dust and powerful water jets, so this socket holds up in exposed outdoor locations, washdown areas and dusty industrial sites. The ABS housing operates reliably across an ambient range of -25 to 75°C, making it a dependable choice where standard power points would not survive. Phosphor bronze pins provide durable, low-resistance contact for a long service life, and the integrated switch means each outlet can be isolated locally.

Straightforward, safe installation
Surface mounting with screw terminals rated for 1.5-6mm² conductors keeps wiring secure under vibration, and the 2 x M20 / 1 x M25 conduit entries give flexible cable routing for a range of installations. The integrated switch lets users isolate connected equipment locally, adding a layer of control and safety on site. At 204mm high by 101mm wide and 83mm deep, it mounts neatly onto walls, posts and plant without crowding the surrounding space.

Australian-standard power
Manufactured to AS/NZS 3133 and AS/NZS 3123, this 56 Series outlet meets Australian requirements for weatherproof socket outlets. The 3 flat pin format accepts standard Australian 10A plugs, and the grey housing is a familiar sight across industrial, utility and commercial installations. As a mains-connected device, it should be installed by a licensed electrician to meet the wiring rules.

Is the Clipsal 56C310-GY weatherproof?
Yes. It carries an IP66 rating, protecting it against dust and high-pressure water jets for use in exposed outdoor and washdown areas.

What plugs does it accept?
It has a 3 flat pin configuration (active, neutral and earth) that accepts standard Australian 10A plugs.

How is the socket mounted and wired?
It is surface mounted with screw terminals rated for 1.5-6mm² cable, and offers 2 x M20 and 1 x M25 conduit entries.
