Tesla Large Dolly 1 Gang Light Switch 35mm Mech

Description

Tesla SW1/LDN. Large Dolly 1 Gang Switch. 16A 250V. NDIS Compatible. Complete.

The Tesla SW1/LDN is a 1 gang large dolly switch — a complete, ready-to-install light switch with the large dolly soft touch mechanism, dolly actuator, and plate all included. The large dolly profile is over four times the size of a traditional switch mechanism, providing an oversized, soft touch rocker that is significantly easier to operate for residents with reduced hand strength, limited dexterity, or visual impairment. Rated 16A 250V. Compliant with AS/NZS 3100 and AS/NZS 3133. NDIS compatible. Sold individually.

• Tesla Large Dolly Range — SW1/LDN 1 Gang Large Dolly Switch
• 1 gang — single switch, one circuit
• Complete switch — large dolly mechanism, actuator, and plate all included, ready to install
• Large dolly profile — over 4 times the size of a traditional switch mechanism
• Soft touch surface — designed for ease of use
• 35mm mechanism format
• Rated: 16A, 250V
• Note: switch mechanism cannot be reconfigured after installation
• Compliant with AS/NZS 3100 and AS/NZS 3133
• NDIS compatible — designed for accessible and assisted living installations
• Also suits recreational clubs and architecturally designed modern homes
• Sold individually

Browse the range online — fast dispatch Australia-wide.

About the Tesla SW1/LDN Large Dolly Switch

The Tesla Large Dolly range is designed to meet the needs of aged care facilities, senior and assisted living homes, NDIS funded accessible housing modifications, and any installation where ease of switch operation is a priority. The large dolly rocker is over four times the area of a standard switch mechanism — a significant step up in accessible design that gives users a much larger target to press with a soft touch surface. This makes the switch easier to operate for those who find standard switches difficult due to reduced grip strength, limited fine motor control, or impaired vision.

The SW1/LDN is the complete 1 gang version — one rocker, one circuit, full assembly ready to wire and fix to the wall. It is the standard Large Dolly (LD) format, as distinct from the XL Large Dolly (LDXN) format which has an even larger dolly profile. Both the LD and LDXN ranges use 35mm mechanisms, are rated 16A 250V, and are NDIS compatible — the choice between them depends on the dolly size required by the installation specification.

An important installation note from the manufacturer: the switch mechanism in the Tesla Large Dolly range cannot be reconfigured after installation. This means the correct switch type (standard single-pole or intermediate/two-way) must be selected at the time of ordering and cannot be changed on site. Ensure the correct wiring configuration is planned before ordering.

The Tesla Large Dolly loaded switch range covers 1 and 2 gang in the standard LD format (SW1/LDN, SW2/LDN) and 1 through 4 gang in the XL format (SW1/LDXN through SW4/LDXN). Unloaded plate-only versions (SW1PL/LDXN through SW4PL/LDXN) are also available for installations where mechanisms are purchased and fitted separately.

Q: What is the difference between SW1/LDN and SW1/LDXN?
A: Both are 1 gang complete large dolly light switches rated 16A 250V and NDIS compatible. The SW1/LDN uses the standard Large Dolly (LD) actuator profile. The SW1/LDXN uses the XL (Extra Large) dolly profile — which is larger again than the LD. Both use 35mm mechanisms. Choose based on the dolly size specified for the installation.

Q: Can the switch mechanism be changed after installation?
A: No — the Tesla Large Dolly switch mechanism cannot be reconfigured after installation. The correct switch type must be selected at the time of ordering. If two-way switching is required, an intermediate mechanism version must be ordered from the outset.

Q: Is this a complete switch or a plate only?
A: The SW1/LDN is a complete switch — the large dolly mechanism, actuator, and plate are all included and assembled. No separate mechanism or plate purchase is required. Connect the cables and fix to the wall.
