Tesla TMCB2P32 Circuit Breaker 32 Amp Two Pole 6kA C-Curve HPC2 Rating

Description

Reliable two-pole protection for demanding circuits.

The Tesla TMCB2P32 is a 32 amp, two-pole miniature circuit breaker from the HPC2 series, with a 6kA breaking capacity built to guard against overload and short circuit in the electrical distribution system. Its C-curve characteristic suits general-purpose circuits, and its double-pole construction isolates both the active and neutral conductors when it trips.

Key Features

• 32A rated current, two-pole (2 Module)
• 6kA (6000A) breaking capacity
• C-curve tripping characteristic
• Manufactured to IEC/EN 60898
• Rated 240V/415V, 50/60Hz
• Bi-metal thermal mechanism for overload tripping protection
• Pillar terminal with clamp; rigid conductor up to 25mm²
• 35mm DIN rail mounting
• Mechanical life 10000 cycles; electrical life 4000 cycles
• IP20 rated; Approval Number V08030

Order online now for fast dispatch Australia-wide.

Why it Matters

Complete double-pole isolation
A two-pole MCB switches the active and neutral conductors together on a single toggle. When the breaker trips on a fault, or is switched off manually, the protected circuit is fully de-energised on both poles. That matters wherever a circuit needs to be positively isolated for maintenance or safe working, rather than relying on breaking the active alone. The two-pole HPC2 occupies 2 modules on the DIN rail while keeping both conductors under one control.

Overload and short-circuit protection in one device
The TMCB2P32 combines two protective functions. A bi-metal thermal element handles sustained overloads, tripping when the rated 32A is exceeded for long enough to risk overheating. For high-energy short circuits, the 6kA (6000A) breaking capacity lets the breaker clear the fault safely. The C-curve characteristic sets the magnetic trip threshold for general-purpose resistive and lightly inductive loads, avoiding nuisance tripping on normal switch-on while still responding quickly to genuine faults.

Built to recognised standards for Australian boards
The breaker is made to IEC/EN 60898 and carries SAA approval number V08030. It is rated 240V/415V at 50/60Hz, with mechanical endurance of 10000 cycles and electrical endurance of 4000 cycles. The 6kA capacity suits commercial, domestic and industrial distribution boards.

Straightforward switchboard fit-off
The 2-module body clips onto standard 35mm DIN rail, and the pillar terminals with clamp accept rigid conductors up to 25mm² for a secure, low-resistance connection. The IP20 enclosure is intended for mounting inside an enclosed switchboard.

Is the Tesla TMCB2P32 a single or double pole breaker?
It is a two-pole (double-pole) MCB. It occupies 2 modules on the DIN rail and switches both the active and neutral conductors together.

What is the breaking capacity of this Tesla MCB?
It has a 6kA (6000A) breaking capacity, rated and manufactured to IEC/EN 60898.

What tripping curve does the TMCB2P32 use?
It uses a C-curve characteristic, which suits general-purpose resistive and lightly inductive circuits found in most commercial and domestic installations.
