Tesla MCB10K3P40 Circuit Breaker 40 Amp 3 Pole C Curve 10kA Rating Energy Class 3

Description

High fault capacity for demanding boards

The Tesla MCB10K3P40 is a 40 amp, three-pole miniature circuit breaker with a 10kA short circuit capacity. It protects against both overload and short circuit while providing a function of isolation, making it suited to installations where prospective fault current exceeds the reach of a standard 6kA device.

Key Features

• 40A rated current, 3 pole
• C curve tripping characteristic
• High short circuit capacity: Icn = Ics = 10kA
• Energy Limiting Class 3
• Protection against overload and short circuit
• Function of isolation
• Contact position indication
• DIN and chassis mount
• Box quantity 4, carton quantity 40

Add to cart for fast dispatch Australia-wide.

Why it Matters

Where 10kA is required
Prospective short circuit current rises the closer a board sits to the supply transformer. Where that figure exceeds a 6kA device rating, a 10kA breaker is needed. With Icn equal to Ics at 10kA, this unit is rated to interrupt its full fault current and remain serviceable afterwards, rather than being rated for a single interruption only.

Energy Limiting Class 3
Class 3 is the highest energy limiting classification applied to miniature circuit breakers. It indicates the breaker clears a fault quickly enough to hold let-through energy low, reducing the thermal and mechanical stress passed on to downstream cabling and equipment during a short circuit.

Isolation and mounting
The breaker provides a function of isolation, so it can be used to positively disconnect the circuit for maintenance. Contact position indication shows the true state of the contacts at a glance. It mounts on either DIN rail or chassis, giving flexibility across switchboard and enclosure builds.

What does a 10kA rating mean on this circuit breaker?
It is the short circuit breaking capacity. The Tesla MCB10K3P40 has Icn equal to Ics at 10kA, meaning it can interrupt a 10,000 amp fault and remain in service.

Is the MCB10K3P40 a three-phase circuit breaker?
Yes. It is a three-pole device, so all three phases are switched and protected together from a single toggle.

Can this breaker be chassis mounted?
Yes. The Tesla 10kA MCB range supports both DIN rail and chassis mounting.
