Hager ESC426S 25A 4 Pole 4NC Contactor

SKU: hagcon4254nc

Product Image Gallery

Product image thumbnail for SKU hagcon4254nc

Product Pricing

$124.13 (ex-GST)

$136.54 (inc-GST)

$136.54

$124.13

(inc-GST)
(ex-GST)

Stock and Availability

  • ⚫︎ In Stock

Trusted premium Hager product - reliable and safe electrical solutions for professionals

Electrotraders USPs

Fast Shipping, Trusted by Government, Easy Returns, Free Shipping over $200


Description

  • Hager ESC426S
  • 4 Pole Contactor
  • 25 Amps
  • 4NC

(hagcon4254nc)

Specifications

Connection
Type of contacts4NC
Number of contacts4
Cross-section flexible conductor1 - 6 mm^2
Cross-section rigid conductor1 - 10 mm^2
Electric current
Rated current25 A
Acceptable current rating AC325 A
Capacity
Number of modules2
Frequency
Frequency50 - 50 Hz
Voltage
Rated impulse withstand voltage Uimp4000 V
Rated insulation voltage Ui440 V
Rated operational voltage Ue400 - 400 V
Command voltage AC230 - 230 V
Command voltage DC0 - 0 V
Use conditions
Operating temperature-10 - 50 DegC
Storage/transport temperature-40 - 80 DegC
Use
Category of useAC-7a/AC-7b
Endurance
Number of mechanical operations100000
Electric endurance in number of cycles30000
Texts
Safety hintHumfree contactors are not suitable for intensive use cases (powered 24/7) and in these cases industrial contactors must be used.
Power
Total power loss under IN6 W
Inrush power absorbed3,20 VA
Dimensions
Height83 mm
Width35,75 mm
Depth60 mm
Equipment
Number of NO contacts0
Number of NC contacts4
With switch for manual switchNo
Installation, mounting
Nominal tightening torque1,20 - 1,20 Nm
SKU hagcon4254nc
Manfacturer Part Number ESC426S
Barcode # 3250612400188
Brand Hager
