CC2525C 25mm Corrugated Flexible Electrical Conduit — 25m Roll

Description

25mm. 25 Metre Roll. Grey. Medium Duty. UV Stabilised PVC.

The Rylec CC2525C is a 25mm grey medium duty corrugated flexible conduit in a 25 metre roll — the same UV stabilised PVC construction and AS/NZS 61386 compliance as the CC2510C 10m roll, with more conduit per coil for larger or multi-run jobs. Sold as a single 25 metre coil.

• Rylec — corrugated flexible PVC conduit
• 25mm nominal diameter
• Medium duty
• UV stabilised PVC — suitable for exposed and outdoor above-ground applications
• Colour: Grey
• Roll length: 25 metres
• Compliant with AS/NZS 61386
• Suitable for general wiring applications and air conditioning cable protection
• Not suitable for direct underground burial with 240V wiring
• Compatible with 25mm corrugated conduit fittings — clip adapters, screwed glands, saddles

Order online now — fast dispatch Australia-wide.

More Conduit Per Coil for Longer 25mm Runs

The CC2525C provides the same 25mm medium duty corrugated conduit specification as the CC2510C, in a 25 metre roll that reduces the need for mid-run joins on longer cable protection runs. The 25mm internal diameter accommodates larger cable bundles and individual cables beyond what fits comfortably in a 20mm conduit — making it the appropriate choice for sub-board cable protection, larger air conditioning installations, and commercial wiring runs with higher cable counts or larger cross-sections.

The UV stabilised grey PVC construction is rated for above-ground outdoor and exposed runs — in roof spaces, along external walls, and in other sun-exposed locations where standard PVC would degrade. The corrugated wall profile flexes without kinking while providing the crush resistance required for the medium duty classification. Not suitable for direct underground burial with 240V wiring.

The CC2510C 10m roll is available for smaller quantity requirements, and the CC2550C 50m roll suits bulk trade use. All three share the same 25mm diameter and require the same 25mm corrugated conduit fittings.

Q: When should I choose 25mm corrugated conduit over 20mm?
A: Choose 25mm when the cable bundle size, individual cable cross-section, or cable count exceeds what fits comfortably in a 20mm conduit. As a general guide, 25mm suits larger individual cables (6mm² and above), higher cable counts, or where a lower conduit fill ratio is required for easier cable pulling.

Q: Is the Rylec CC2525C suitable for outdoor use?
A: Yes for above-ground outdoor applications — the UV stabilised PVC resists UV degradation in exposed outdoor locations. Not suitable for direct underground burial with 240V wiring.

Q: What fittings suit the CC2525C?
A: 25mm corrugated conduit fittings — clip adapters, screwed glands, and saddles specified for 25mm conduit. Confirm the fitting size when ordering accessories.

Warranty

This product is backed by an extended manufacturer warranty - click here for details.
