Tesla TESMB18 Mounting Block 18mm Deep — Power Point & Light Switch

Description

Tesla MB18. Mounting Block 18mm Deep. White. 84mm Centres. Single Outlet.

The Tesla MB18 is an 18mm deep surface mounting block in white — for mounting standard size power points, light switches, and accessories onto solid walls such as brick, concrete, and masonry where no wall cavity is available. 84mm mounting centres. Short mounting screws supplied. Multiple fixing points. No special brackets required. Sold individually.

• Tesla — MB18 Mounting Block, 18mm Deep
• White
• Suits all standard size power points, light switches, and accessories
• 84mm mounting centres
• Dimensions: 117mm L x 73mm W x 18mm H
• Horizontal and vertical mount
• Short mounting screws supplied
• Multiple fixing points
• No special brackets required
• Suitable for one outlet — single gang only
• Suitable for residential and commercial environments
• Sold individually

Order online now — fast dispatch Australia-wide.

Where the Tesla MB18 Mounting Block Fits

Surface mounting blocks are used when a power point or light switch needs to be installed on a solid wall surface — brick, concrete, masonry, or any surface where there is no cavity behind the wall for flush mounting. The mounting block sits on the wall face and provides the depth behind the plate for cable housing and the fixing centres for the plate screws. The MB18 is the 18mm depth option — 2mm deeper than the MB16 — providing slightly more internal depth behind the plate for cable housing while maintaining a low-profile appearance off the wall surface.

The MB18 suits single outlet plates only — one power point or one switch plate per block. Multiple fixing points on the block allow the mounting screws to be positioned to suit different wall fixing requirements. Short mounting screws are supplied with each block for securing the wall plate to the block face. Both horizontal and vertical mounting positions are supported.

The Tesla MB range covers shallow through to deep mounting options: MB16 (16mm), MB18 (18mm), MB34 (34mm), with the WPMB (41mm weatherproof with 25mm end entries) and RMB/A (44mm recessed) also available. Choose the depth based on the cable size, installation type, and available space at the wall position.

Q: What is the difference between MB16, MB18, and MB34?
A: All three are white mounting blocks with 84mm fixing centres and the same 117mm × 73mm footprint — the only difference is the depth. MB16 is 16mm deep (shallowest), MB18 is 18mm deep, and MB34 is 34mm deep (most internal cable space). Choose the depth based on the cable size and available space behind the plate.

Q: Can the MB18 be mounted both horizontally and vertically?
A: Yes — the MB18 supports both horizontal and vertical mounting positions, consistent with standard power point and light switch plate orientations.

Q: Does the MB18 come with screws?
A: Yes — short mounting screws are supplied with the MB18 for securing the wall plate to the block face.
