Tesla ST19 Infrared 120 Degree Motion Sensor Wall Mount 240V PIR IP66

Description

Weatherproof 120 degree infrared sensing with manual override.

The Tesla ST19 is a 120 degree infrared motion sensor (PIR) that switches lighting automatically when movement is detected up to 12 metres away. Rated IP66 with a manual override function and an adjustable time delay, it combines automatic, convenient, safe, and energy-saving operation, identifying day and night automatically.

Key Features

• Tesla ST19 — 120 Degree Infrared Motion Sensor (PIR)
• Detection range: 120 degrees
• Detection distance: 12m max (below 24°C)
• Manual override function
• Automatic day / night detection
• Adjustable time delay: approx. 10 sec to 30 min
• Power: 220-240V AC / 50-60Hz — approx. 0.5W consumption
• Rated load: max 1000W LED, 300W energy-saving, 1200W incandescent
• IP66 weatherproof rating
• Installation height: 1.8-2.5m
• Detection moving speed: 0.6-1.5 m/s

Order now for fast dispatch Australia-wide.

Why the Tesla ST19 Sensor Suits Australian Installs

Weatherproof coverage for exposed positions
The ST19 carries an IP66 rating, protecting it against dust ingress and powerful water jets from any direction. That makes it one of the more robust sensors in the range for genuinely exposed outdoor positions — external walls, unsheltered entries, and sites facing driving rain — where a lower-rated sensor would struggle. It watches a 120 degree field and detects movement up to 12 metres away.

Adjustable timing plus manual override
The ST19 offers an adjustable time delay from around 10 seconds up to roughly 30 minutes — a longer maximum than the shorter-run sensors, useful where a light needs to stay on well after the last movement. A manual override function lets you force the load on or off independently of the sensor, handy for cleaning, extended work, or holding a light on when needed. It reads day and night automatically, so lights only trigger after dusk, and at approximately 0.5W the sensor costs almost nothing to run.

Handles real lighting loads
The ST19 switches up to 1000W of LED load (or 1200W incandescent) on 220-240V, covering substantial lighting circuits for residential and light commercial sites. It installs at a height of 1.8 to 2.5 metres. Wiring must be carried out by a licensed electrician in accordance with Australian requirements. Tesla Electrical Components is an Australian-based brand headquartered in Wetherill Park, NSW, and this sensor is sold individually and shipped Australia-wide.

Q: Can the Tesla ST19 be used outdoors?
Yes. The ST19 is rated IP66, protecting it against dust and powerful water jets, so it suits exposed outdoor positions such as external walls and unsheltered entries.

Q: How long can the Tesla ST19 keep a light on?
The ST19 has an adjustable time delay from approximately 10 seconds up to around 30 minutes, plus a manual override function to force the load on or off.

Q: What load can the Tesla ST19 switch?
On 220-240V it handles a maximum of 1000W LED, 300W energy-saving lamp, or 1200W incandescent.

Warranty

This product is backed by an extended manufacturer warranty - click here for details.
