2.5mm Twin and Earth TPS Electrical Cable White 2C+E 450/750V - 10m Cut

Description

Reliable fixed wiring starts with the right cable.

This 2.5mm twin and earth flat TPS cable delivers 450/750V-rated copper wiring for Australian electrical installations, cut to the length you actually need. Every cut is supplied as one continuous run, so you are not joining short ends partway through a circuit.

Key Features:

• 2.5 mm² twin active and earth (2C+E) flat TPS configuration
• 7/0.67 mm stranded annealed copper conductors
• 450/750 V voltage rating, built to AS/NZS 5000.2
• V-90 PVC insulation rated to a 90°C maximum conductor temperature
• 3V-90 PVC white sheath with red, black and green/yellow earth cores
• Compact 12.4 mm x 5.5 mm flat profile with a 20 mm bend radius
• Supplied as one continuous length per cut – choose 10m to 50m cuts or a full 100m roll
• Please choose cable type and length carefully as there are no refunds or exchanges on cut cable.
• This product may attract a delivery surcharge if delivering to a non-metropolitan area.

Add to cart and select the length that suits your job.

Why it Matters

Buy the length, not the drum

Paying for a full 100m drum when the job needs 30m ties up money and leaves part-rolls cluttering the van. Cut lengths from 10m to 50m let you order to the job, while the 100m roll covers ongoing work and restocking. Whichever you choose, the cable arrives as a single continuous length ready to run.

Built for Australian installations

The cable is constructed to AS/NZS 5000.2, the Australian standard for electric cables rated up to 450/750V. Installation must comply with AS/NZS 3000 (the Wiring Rules), and the current-carrying capacity for your circuit depends on the installation method as determined under AS/NZS 3008 – sizing and installation are jobs for a licensed electrician.

A flat profile that is easy to run

The flat TPS shape sits neatly against framing and through cavities, and the 20 mm bend radius makes clean direction changes without stressing the insulation. The 90°C-rated V-90 PVC insulation and easy-identify red, black and green/yellow cores keep terminations quick and unambiguous.

What is 2.5mm twin and earth cable used for?
It is a general-purpose fixed wiring cable for domestic, commercial and industrial installations in Australia. Circuit selection, current capacity and installation method must be determined by a licensed electrician in accordance with AS/NZS 3000 and AS/NZS 3008.

What voltage and temperature is this cable rated for?
It carries a 450/750 V voltage rating to AS/NZS 5000.2, with V-90 PVC insulation rated to a maximum conductor temperature of 90°C.

Is the cable supplied in one continuous length?
Yes. Each cut length from 10m to 50m is supplied as a single continuous run with no joins, and the 100m option is supplied as a full roll. Choose your length carefully, as cut cable cannot be refunded or exchanged.
