Clipsal 56SO310-RO 56 Series Surface Socket IP66 250V 10A 3 Flat Pin Orange

Description

Weatherproof power where the job gets tough.

The Clipsal 56SO310-RO is an IP66-rated surface-mount socket outlet built for exposed, wet and demanding sites. Its chemical resistant orange enclosure stands up to harsh environments while delivering a reliable 10A, 250V single-outlet connection.

Key Features

• IP66 dust and water protection (AS 60529)
• 10A rated current, 250V AC
• 3 flat pin configuration (1P + N + E)
• Surface / external mounting
• ABS enclosure, brass contact screws
• Screw terminals: 1.5–6 mm² rigid or stranded cable
• Cable outer diameter 7–16 mm
• Operating temperature -25 to 75 °C
• Complies with AS/NZS 4417.1 and AS/NZS 3112

Order online now for fast dispatch Australia-wide.

Built for Australian Site Conditions

The 56 Series is a proven workhorse across Australian industry, trusted on job sites where reliability isn't negotiable. The IP66 rating seals out dust and high-pressure water, making this socket suited to outdoor, washdown and exposed installations where a standard GPO simply won't survive. Whether it's mounted on a shed wall, a plant room, or an exposed external surface, the sealed enclosure keeps the connection protected year-round.

Chemical Resistant Enclosure

The chemical resistant orange (RO) housing is engineered to withstand contact with aggressive substances that would degrade a standard enclosure over time. This makes it a sound choice for environments where cleaning agents, oils or other chemicals are part of daily operation. The high-visibility orange finish also aids quick identification on busy sites, helping crews locate the outlet at a glance.

Simple, Secure Termination

Termination is straightforward. The screw terminals accept 1.5–6 mm² rigid or stranded cable, and the gland accommodates cable from 7 to 16 mm outer diameter — giving electricians real flexibility across a range of installs. Brass contact screws and an ABS body keep the unit robust through repeated use.

Is the 56SO310-RO weatherproof?
Yes. It carries an IP66 rating conforming to AS 60529, protecting against dust ingress and powerful water jets, so it holds up in outdoor and washdown settings.

What cable size does it take?
The screw terminals accept 1.5 to 6 mm² rigid or stranded cable, with a cable outer diameter range of 7 to 16 mm.

What pin configuration is the 56SO310-RO?
It is a 3 flat pin socket outlet wired 1P + N + E, rated 10A at 250V AC.
