Hager ADM425T 25 Amps 4 Pole RCBO Safety Switch 6kA
SKU: hagrcb425
Product Image Gallery
Product Pricing
$170.63 (ex-GST)
$187.69 (inc-GST)
$187.69
$170.63
(inc-GST)
(ex-GST)
Stock and Availability
- ⚫︎ In Stock
Trusted premium Hager product - reliable and safe electrical solutions for professionals
Electrotraders USPs
Description
- Hager ADM425T
- 4 Pole RCBO 6kA
- 25 Amps
(hagrcb425)
Specifications
| Electric current | |
| Rated current | 25 A |
| Rated residual operating current Idn | 30 mA |
| Rated current -25DegC | 31,70 A |
| Rated current at -20DegC | 31,20 A |
| Rated current -15DegC | 30,60 A |
| Rated current -10DegC | 30 A |
| Rated current -5DegC | 29,40 A |
| Rated current at 0DegC | 28,90 A |
| Rated current 5DegC | 28,30 A |
| Rated current 10DegC | 27,60 A |
| Rated current 15DegC | 27 A |
| Rated current at 20DegC | 26,40 A |
| Rated current 25DegC | 25,70 A |
| Rated current 30DegC | 25 A |
| Rated current 35DegC | 24,30 A |
| Rated current at 40DegC | 23,60 A |
| Rated current at 45DegC | 22,80 A |
| Rated current at 50DegC | 22 A |
| Rated current 55DegC | 21,20 A |
| Rated current 60DegC | 20,40 A |
| Rated short-circuit breaking capacity Icn under 230 V AC according to IEC 61009-1 | 6 kA |
| Architecture | |
| Curve | C |
| Neutral position | Right |
| Type of pole | 4P |
| Number of protected poles | 4 |
| Capacity | |
| Number of modules | 4 |
| Safety | |
| Residual current type | A |
| Ingress Protection (IP) class | IP2X |
| Voltage | |
| Type voltage supply | AC |
| Rated operational voltage Ue | 230 - 415 V |
| Rated insulation voltage Ui | 500 V |
| Dielectric strength value of power frequency | 2 kV |
| Rated impulse withstand voltage Uimp | 4000 V |
| Overvoltage category according to IEC 60947-1 | 3 |
| Installation, mounting | |
| Nominal tightening torque top terminal | 2 - 2 Nm |
| Nominal tightening torque down terminal | 2 - 2 Nm |
| Nominal tightening torque | 2 - 2 Nm |
| 360?ø mounting position possible | Yes |
| Type of top connection for modular devices | Screw terminal |
| Type of bottom connection for modular devices | biconnect, Bypass |
| Main electrical attributes | |
| Rated short-circuit breaking capacity Icn AC according to IEC 60898-1 | 6 kA |
| Frequency | |
| Frequency | 50 - 50 Hz |
| Connection | |
| Cross-section of input with screws, for flexible conductors | 1 - 16 mm^2 |
| Cross-section of input with screws, for massive conductors | 1 - 25 mm^2 |
| Use conditions | |
| Class of energy limitation I^2t | 3 |
| Operating temperature | -25 - 40 DegC |
| Dimensions | |
| Height | 84 mm |
| Width | 71 mm |
| Depth | 70 mm |
| Power | |
| Total power loss under IN | 12,30 W |
| SKU | hagrcb425 |
| Manfacturer Part Number | ADM425T |
| Barcode # | 3250611032960 |
| Brand | Hager |
